PISTON 94-08 KTM620 640 101 C, FORGED WOSSNER KIT 8524DC

Sale!
PISTON 94-08 KTM620 640 101 C, FORGED WOSSNER KIT 8524DC

PISTON 94-08 KTM620 640 101 C, FORGED WOSSNER KIT 8524DC

Original price was: $247.20.Current price is: $173.60.

16 in stock

SKU: 56-W181.C Category:

Description

  • Piston Kit: Wossner 8524DC, with a 101.02mm bore (+0.02mm)

  • Applications: KTM 620LC4, KTM 625, KTM 640 LCA/SX/Duke/Supermoto, produced between 1994 and 2007

  • Features:

    • Wossner forged pistons known for superior strength and design

    • Engineered for efficient combustion chamber heat transfer to cylinder walls

    • Elliptical design for a more uniform bearing surface under piston heat expansion, preventing collapse

  • Manufacturing: Made in Germany

  • Additional Parts:

    • Lock: CW22

    • Pin: WP009

    • Ring Set: 1010XSY

  • Specifications:

    • Displacement: 600 cm³

    • Hub Stroke: 76.00mm

    • Clearance: 0.06mm

    • Compression Ratio: OEM specified (11.70:1)

    • Dome Volume: +7.60cm³

    • Compression Height: 26.50mm

    • Theoretical Weight: Not provided
