RMStator Generator Stator Kit With Voltage Regulator Rectifier RMS900-106078

Description

RMStator Generator Stator Kit With Voltage Regulator Rectifier RMS900-106078

Brand new Kit Generator Stator + Voltage Regulator

• Direct replacement to your original unit
• Plug-and-play, direct fit, easy installation
• All shipped products are tested

Generator Stator

• Highest grade of lamination materials
• Highest grade of copper winding, resistant to 200 degrees Celsius
• Pick up pulsar coil included
• Connector included
• Rubber grommet included

Regulator

• No assembly required
• Higher grade of electric components
• Improved heat sink and charging capabilities
• The quality exceeds the OEM equipment
• We have even included the opposite connector (main harness side) as we know these are often melted/corroded/defective and a major cause for repetitive electrical issues

All item pictures are accurate; if in doubt, do not hesitate to compare our item to your original part.

Technical Data

Stator Dimensions
Interior diameter : 42 mm
Exterior diameter : 107 mm
Thickness : 18 mm
Length of wires stator to grommet : 120 mm
Length of wires grommet to plug : 200 mm
Length of pickup coil’s wire to grommet : 75 mm

Other specifications :

Number of wires : 5
Number of plugs : 2
Number of pins : 5

Wire to wire resistance :

Alternator : White to White = 0.8 ohms +-20%
Pickup : Blue/White to White/Green = 250 ohms +-20%

Regulator Dimensions
Width : 89 mm
Length : 91 mm
Height: 27 mm
Fixation holes center to center : 65 mm

Other specifications :
Number of plugs : 1
Number of pins : 6

RMSTATOR are committing to innovate in finding clever ways to design more efficient parts that produce better results than any other part on the market.

We do not just sell electrical parts for powersports, we solve problems. RMSTATOR take pride in designing & manufacturing more efficient parts, providing all the information necessary for an easy and reliable installation, and supporting the customer before, during, and after the sale.

THE POWER IN POWERSPORTS

Brand: RMStator
Part Number: RMS900-106078

Fitment:

• 2006-2018 Yamaha Raptor 700R YFM700R

Note: Image is for reference only, actual product may vary slightly.

OEM Numbers:
106078-R00
